Insulating gland, DP...H, DP...H BK type

Insulating gland, DP...H, DP...H BK type

Product name Insulating gland, DP...H, DP...H BK type

Category Made of plastic

Operating temperature [°C] -30 ÷ +80

Colour grey (RAL 7035), black BK (RAL 9005)

Material body: polyamide 6; seal - PVC

Flammability class UL 94 V2

IP degree of protection IP68

Note! Gland, nut and sealing washer in a kit.

No data

Type Name Language Updated at Download File type
Catalog card ERGOM_Dlawnica_izolacyjna_typu_DP_H_DP_H_BK_EN.pdf EN 2026-03-12 Download 363.49 KB PDF
Catalog card ERGOM_Dlawnica_izolacyjna_typu_DP_H_DP_H_BK_PL.pdf PL 2026-03-12 Download 383.88 KB PDF

No data
